5.5A High-Voltage Servo Drive 220V for Precision Motion

The JASND10002-23B is a 5.5A High-Voltage Servo Drive 220V built for mid-size precision servomotors on machines with a 220 V supply. Distributed by Lyenwsin, this flagship fieldbus drive runs on an ARM-plus-FPGA dual-chip platform that emphasizes high dynamic response, fast settling, smooth travel, and minimal vibration for precise positioning tasks.

Why the Architecture Matters

Dividing real-time and supervisory tasks across the ARM and FPGA keeps the current loop fast and deterministic. That is what lets the drive manage short settling times on machines that index rapidly between positions without ringing.

Application Scenarios

This drive is a fit for mid-size precision servomotors on machines with a 220 V supply:

• Robotics: joint axes and tool changers that must settle quickly between moves.
• Packaging machinery: servo-driven filling, capping, and wrapping stations with repeatable cycle times.
• CNC machine tools: auxiliary and feed axes where 220 V is the available line.
• Semiconductor and battery equipment: precision positioning and stacking stations.

Selection Advice

Confirm voltage and current

5.5 A at 220 V suits mid-size servomotors. Verify the motor’s ratings and keep headroom for acceleration peaks.

Use the damping tools

Auto-gain tuning, multiple notch filters, and the disturbance torque observer reduce vibration at structural resonances and reject external load changes, preserving tracking accuracy through a production cycle.

Match the network

RS485, CANopen, EtherCAT, and ProfiNET plus switchable control modes let the drive fit a variety of PLC ecosystems and fieldbus standards.

Ratings at a Glance

• Supply voltage: 220 V, output current 5.5 A
• Fieldbus: RS485, CANopen, EtherCAT, ProfiNET
• Control modes: CSP, CSV, CST, PP, PV, PT, HM
• Auto-gain tuning, notch filters, disturbance torque observer

Distributor Support

Lyenwsin can confirm stock, provide configuration files, and help match the drive to your servomotor and PLC. Contact our technical support team for application assistance and current pricing before placing your order.
