5.5A Dual-Axis Servo Drive for Multi-Axis Automation

The JAWD7502-23B is a 5.5A Dual-Axis Servo Drive delivering two servo axes from a single enclosure on a 220 V supply. Available through Lyenwsin, it is rated at 5.5 A output per channel, supports gantry synchronization, and relies on auto-tuning plus filters to keep vibration low while a disturbance observer rejects external load interference. RS485, CANopen, and EtherCAT connect it to the machine bus, so the same hardware fits a wide range of PLC ecosystems.

Panel Space Economy

By consolidating two channels into one drive, cabinet wiring and volume drop compared with separate single-axis units. This is practical in compact CNC and packaging frames where every cubic centimeter of cabinet volume matters, and it reduces the number of spare parts a maintenance team must hold.

Gantry Coordination

Gantry synchronization holds both channels locked together, keeping a shared load level as it moves. The integrated design removes the timing overhead of matching two independent drives, which is especially useful on Cartesian robots and long-axis transfer systems.

Commissioning Aids

Auto-tuning and notch filtering speed setup and damp structural resonances, while the configurable I/O tailors the drive to the machine’s existing controls. This shortens the period between installation and first production runs and lowers the engineering effort on each new line.

Rating and Interface Notes

• Supply voltage 220V, output current 5.5A per axis
• Dual-axis integrated design with gantry synchronization
• RS485, CANopen, and EtherCAT
• Auto-tuning, filters, disturbance observer

Applications

The drive targets CNC machine tools, factory automation, semiconductor equipment, robotics, battery manufacturing, material handling, and packaging machinery. It pairs well with smaller dual-axis servo installations such as Cartesian pickers and synchronized conveyor sections.

Distributor Guidance

Lyenwsin provides technical support for motor pairing, gantry alignment, and fieldbus configuration. Confirm the per-axis current requirement of each servomotor against the 5.5 A rating before ordering. Contact us for a quote and delivery schedule.
