60J1887-440 3.3 N·m NEMA24 Stepper Motor - 85 mm

Equal Torque from a Shorter 3.3 N·m NEMA24 Stepper Motor

The 60J1887-440 is a 3.3 N·m NEMA24 Stepper Motor, a 2-phase 60 mm-frame motor, 85 mm long, with 3.3 N·m at 4.0 A and an 8 mm shaft. It retains the torque of its 100 mm sibling in a shorter body, trading a little length for a smaller motor-cavity requirement.

Equal Torque, Reduced Length

Holding the same 3.3 N·m while shortening the body suits machines whose depth is constrained. The identical current and shaft simplify parts commonality with the longer NEMA24 variant, which helps maintenance teams keep a smaller spare-parts stock.

Data

• Frame: NEMA24 (60 mm)
• Body length: 85 mm
• Phase current: 4.0 A
• Holding torque: 3.3 N·m
• Shaft: 8 mm
• Type: 2-phase, open-loop

Application Scenarios

Textile roller drives and food-processing feed belts value a motor with stable torque and low vibration for consistent line speed; the compact length helps where guards or adjacent components limit space. In compact CNC equipment the motor drives small axes and tool-change mechanisms, while packaging machinery uses it for indexing conveyors and labelers. Factory automation pick mechanisms and compact robot arms take advantage of the NEMA24 interface to carry moderate payloads with repeatable positioning.

Selection Advice

Select a driver rated for at least 4.0 A and confirm the supply bus supports the voltage needed to reach your target speed under load. Because torque decreases with speed, benchmark the required torque at the operating RPM rather than at standstill. Keep the motor surface free of enclosure contact that blocks airflow; low motor heating maintains torque through extended operation, an important factor in continuous production lines.

Drive Matching

A 4.0 A-capable driver and standard 8 mm coupling hardware complete the axis. The NEMA24 interface provides a stable mounting without excessive footprint. Lyenwsin offers the motor, driver and support for OEM and integrator projects.
