• 3 phase, NEMA42 frame size
• 220 mm long
• 6.0 A phase current
• 22 N.m holding torque
• 19 mm shaft size
• Built with high quality materials.High precision, low motor heating, and low vibration。
The 110J12220-360 is a 22 N·m 3-Phase Stepper Motor producing 22 N·m of holding torque at a 6.0 A phase current, built in a NEMA42 frame with a 220 mm body length. It is a reliable open-loop axis for CNC machine tools, packaging, and food processing equipment where the load calls for more torque than a NEMA34 can provide but a full servo system is not required.
The NEMA42 frame is a common size for CNC and industrial axis loads that need more torque than a NEMA34 but do not require full servomotor closed loop control. The 19 mm shaft delivers torque through standard couplings, and the rigid flange ensures repeatable mounting alignment.
Three-phase operation lowers torque ripple, and the 6.0 A winding is wound to keep resistive heating in check. This matters when the axis holds position under load for long periods, as lower temperature rise preserves both torque repeatability and bearing life.
The 19 mm shaft delivers torque through standard couplings. The NEMA42 flange gives a rigid, repeatable mount. Open-loop control means the drive issues step and direction pulses directly, so no feedback loop or tuning is needed.
Its torque and frame size fit compact CNC equipment, packaging machinery, factory automation, compact robotic mechanisms, textile machinery, printing machinery, and food processing. Heavy load CNC axis and rotary table indexing work rely on its 22 N·m holding torque.
Pair the motor with a 3-phase stepper drive rated for at least 6.0 A output. The deterministic open-loop response makes it straightforward to tune cycle times, and low vibration suits machinery where smooth output affects product quality. Lyenwsin provides drive pairing and sizing guidance for heavy-load axis applications.
| Model | 110J12220-360 |
| Phase | 3 |
| Step Angle（deg） | 1.2 |
| Holding Torque(N·m) | 20 |
| Rated Current（A） | 6 |
| Phase Resistance(ohm) | 1.24 |
| Phase Inductance（mH） | 22 |
| Detent Torque（mN·m） | 6800 |
| Rotor inertia（g·cm²） | 19600 |
| Insulation Class | B |
| Number of Leads | 3 |
| Weight（kg） | 11 |
| Length（mm） | 220 |
| Matched Drive | 3DM2080 |
| Frame Size（NEMA） | 42 |
| Shaft Diameter（mm） | 19 |
| Frame Size(mm) | 110 |
