14A Fieldbus Servo Drive 220V for General Machine Duty

The JAND20002-23B is a 14A Fieldbus Servo Drive 220V in the general series, designed for general machine duty. Distributed by Lyenwsin, the drive is assembled around an ARM processor, a large programmable logic array (FPGA), and an IPM power module, using optimized PID control to achieve fully digital regulation of position, velocity, homing, and torque. High integration, auto-tuning, and resonance frequency identification give it steady behavior across a machine.

Digital Control Foundation

The combination of ARM, FPGA, and IPM module yields a compact, reliable power stage. Optimized PID loops drive position, speed, homing, and torque accuracy digitally, removing analog drift from the motion chain.

Auto-Tuning and Resonance ID

Auto-tuning sets gains without manual trial-and-error, while resonance frequency identification lets the drive damp structural response. The result is cleaner motion and a shorter commissioning curve.

I/O and PLC Compatibility

Rich I/O includes limit switch, homing reference, and probe interfaces. The drive is compatible with mainstream PLCs from Inovance, Leadshine, Omron, Delta, and Beckhoff, and it connects over RS485, CANopen, or EtherCAT.

Ratings

• Supply voltage 220V, output current 14A
• ARM + FPGA + IPM power stage with PID control
• RS485, CANopen, and EtherCAT
• Rich I/O for limit, homing, and probe; broad PLC compatibility

Application Scope

This drive serves CNC machine tools, factory automation, semiconductor equipment, robotics, battery manufacturing, material handling, and packaging machinery. Its 14 A output supports larger servomotors in general cycle duty where dependable torque and repeatable positioning are required across continuous three-shift operation.

Procurement and Support

Lyenwsin supplies datasheets, wiring references, and application guidance for this fieldbus servo drive. Confirm that your servomotor’s rated and peak current fit within the 14 A output and that the 220 V supply matches your panel. Our technical support team can also help with encoder selection, homing wiring, and fieldbus parameter setup to shorten commissioning.
