5.5A Fieldbus Servo Drive 220V for Compact Motion

The JAND7502-23B is a 5.5A Fieldbus Servo Drive 220V in the general series, fitting typical robotics and packaging axes that need smooth torque without an oversized power stage. Distributed by Lyenwsin, it combines an ARM processor, a large FPGA, and an IPM power module to deliver fully digital position, velocity, homing, and torque control through optimized PID algorithms.

Balanced Current for Mid-Size Axes

At 5.5 A, this drive sits in the mid range of the general series. High integration, auto-tuning, and resonance frequency identification keep the motion stable with a compact footprint, which matters on machines with many axes sharing one panel.

Application Scenarios

Machines with 220 V mains and mid-size servomotors are the natural fit:

• Robotics: arm and wrist axes on assembly and palletizing robots that index continuously.
• Packaging machinery: servo-driven feeders, sealers, and labelers with repeatable cycle timing.
• Material handling: indexing conveyors and lift axes in DC-bus machine layouts.
• Semiconductor and battery equipment: precision positioning stations on a 220 V line.

Selection and Integration Advice

Commission with auto-tune

Auto-tuning and resonance frequency identification remove most manual gain staging. Once structural modes are identified, the drive damps them, so production can begin sooner.

Use the rich I/O set

Limit switches, homing reference, and probe signals connect directly. The drive is compatible with mainstream PLCs from Inovance, Leadshine, Omron, Delta, and Beckhoff, simplifying integration into existing cabinets.

Match the network and current

RS485, CANopen, and EtherCAT carry the motion bus. Verify the servomotor’s rated current against the 5.5 A output and keep acceleration peaks within the drive’s duty capability.

Technical Notes

• Supply voltage: 220 V, output current 5.5 A
• ARM + FPGA + IPM with optimized PID control
• Fieldbus: RS485, CANopen, EtherCAT
• Rich I/O and broad PLC compatibility

Distributor Support

Lyenwsin provides datasheets, configuration notes, and motor matching guidance for this fieldbus servo drive. Contact our technical support team for application advice and current availability before ordering.
