8.4A 2-Phase Stepper Drive with 24-110 VDC Supply

8.4A 2-Phase Stepper Drive with Wide Supply Range

The 2DM860 is an 8.4A 2-Phase Stepper Drive rated for supply inputs of 24-110 VDC, or 18-80 VAC when an AC source is preferred. Its output stage delivers up to 8.4 A to the motor phases, giving it headroom for larger two-phase stepping motors that need sustained current during acceleration and at speed. The wide input window is one of its strongest selling points for distributors.

Command Modes

The drive accepts both Pulse/Dir and CW/CCW pulse formats. Pulse/Dir is the conventional choice when connecting to a PLC or motion card, while CW/CCW mode is convenient when the host controller already emits separate clockwise and counterclockwise pulse trains. No external protocol converters are required between the drive and a standard pulse-output controller.

Motion Quality

Internal tuning is aimed at low noise and low vibration, producing smooth motion across the operating speed range. On equipment where micro-step ripple or acoustic noise affects finished parts, such as compact CNC machines and printing equipment, the quieter output reduces mechanical stress on couplings and guides.

Protection and Durability

• Supply voltage: 24-110 VDC (18-80 VAC)
• Maximum output current: 8.4 A
• Command modes: Pulse/Dir, CW/CCW
• Protection: overcurrent, overvoltage, undervoltage

Overcurrent, overvoltage, and undervoltage monitoring shut down the output stage when a fault condition appears, protecting both the drive and the connected motor from sustained abuse. This is a practical benefit on 24 VDC control panels and on higher-voltage rails where transient spikes are more common.

Target Applications

The 2DM860 maps to Industrial Automation, packaging machinery, compact CNC equipment, robotics, automated handling mechanisms, textile machinery, printing machinery, and food processing lines. Its wide supply window and 8.4 A output make it a workable choice for axes that combine high torque demand with existing multi-voltage DC buses, and it is a common upgrade for OEMs standardizing on one driver platform.
