JASND30002 3000W Servo Drive 240V, 50 A, Absolute Encoder

3000W Servo Drive 240V with High-Current Output

The JASND30002 is a 3000W Servo Drive 240V unit delivering 3000 W with a 50 A maximum output current, running main power from three-phase AC 180-240 V and control power from single-phase AC 180-240 V at 50/60 Hz. The high current rating supports motors with low impedance windings that need substantial drive capability at a 220 V class bus.

Drive Performance and Auto-Tuning

An ARM+FPGA controller sustains a 625 kHz current-loop sample rate, with PWM switching at 8, 10.667, or 16 kHz. One-parameter loop configuration and one-click auto-tuning accelerate commissioning, while adaptive vibration suppression, an adaptive notch filter, and one-click resonance elimination address mechanical resonance automatically.

Feedback and Connectivity

Absolute 17/23-bit feedback maintains position integrity over power events. Two −10 V to +10 V analog inputs, one matching output, 8 digital inputs, and 5 digital outputs cover command and interlock needs, with Type-C and RS485 for setup and serial communication.

Specifications

• Rated power: 3000 W
• Max output current: 50 A
• Main power: Three-phase AC 180-240 V, 50/60 Hz
• Control power: Single-phase AC 180-240 V, 50/60 Hz
• Analog inputs: 2 × −10 V to +10 V
• Analog output: 1 × −10 V to +10 V
• I/O: 8 digital in, 5 digital out
• Feedback: 17/23-bit absolute encoder
• Interfaces: Type-C, RS485
• Braking: built-in resistor, external supported
• Protection: overvoltage, undervoltage, overspeed, overload

Braking and Protection

A built-in braking resistor handles typical regeneration and an external resistor can be added for heavy deceleration loads. Overvoltage, undervoltage, overspeed, and overload guards protect the power stage.

Safety and Value-Add

A secondary encoder function, built-in brake output, and STO safety interface support safe torque off and centralized braking control.

Application Fit

It is suited to CNC machine tools, Industrial Automation, semiconductor equipment, robotics, battery manufacturing, material handling, and packaging where a 220 V three-phase high-current servo drive is required. The high current output is the main differentiator for machines using low-inductance motors that demand large peak current.
