• 3 phase, NEMA 52 frame size
• 205 mm long
• 6.8 A phase current
• 28 N.m holding torque
• 24 mm shaft size
• Integrated 2,500 P/R,
• high efficiency,low noise,fast response, high torque, high speed and low vibration。
This closed-Loop stepper motors is made of high-quality materials, featuring full closed-loop control, high efficiency, low heat, low noise, smooth and precise operation, fast response, high torque and high speed.
| Model | 130J12205EC-2500 |
| Phase | 3 |
| Frame Size（NEMA） | 52 |
| Length(mm) | 205 |
| Step Angle（deg） | 1.2 |
| Holding Torque（N·m） | 28 |
| Rated Current（A） | 6.8 |
| Phase Resistance（ohms） | 0.8 |
| Phase Inductance（mH） | 11.3 |
| Rotor inertia（g·cm²） | 34900 |
| Weight（kg） | 13.44 |
| Matched Drive | 3HCS2208H、3HCS2208H-17BC-EC |
| Encoder Resolution | 2500P/R |
| Shaft Diameter（mm） | 24 |
| Frame Size（mm） | 130 |
