JAND4002-20B

400W 180-240VAC Servo Drive with Absolute Encoder Feedback

Product Categories

JAND4002-20B

• Rated power 400 W,max output current 9.6A
• 180-240VAC
• 2 simulate command input,-10V~10V
• IO : 8 DI, 5 DO
• 17/23-bit absolute encoder
• RS232, RS485 interfaces
• No built-in braking resistor, supports external braking resistor
• Overvoltage, undervoltage, overspeed, overload protection

The JAND4002-20B is a 400 W high-voltage servo drive for 180-240 VAC supplies, with a 9.6 A maximum output current. Its peak-like current capability makes it a strong fit for acceleration-heavy axes despite its modest continuous power.

Peak Current for Fast Moves

A 9.6 A maximum output current supports elevated acceleration torque on light servo motors, shortening settling time on indexing and positioning moves common in assembly equipment.

Feedback and Command Inputs

The drive reads 17/23-bit absolute encoders. Two analog command inputs accept -10 V to 10 V, served by 8 digital inputs and 5 digital outputs for machine interfacing.

Communications

RS232 and RS485 interfaces are both included. RS232 is used for direct, single-drive tuning; RS485 allows the drive to participate in a shared network with other axes and a host controller.

External Braking Resistor

No built-in braking resistor is fitted, so an external braking resistor is needed when the load regenerates substantial energy during deceleration.

Protection Functions

Overvoltage, undervoltage, overspeed, and overload protection are standard.

Typical Applications

CNC machine tools, factory automation, semiconductor equipment, robotics, battery manufacturing, material handling, and packaging machinery.

Key Specifications

  • Rated power: 400 W
  • Max output current: 9.6 A
  • Supply voltage: 180-240 VAC
  • Analog command inputs: 2 (-10 V to 10 V)
  • Digital I/O: 8 inputs, 5 outputs
  • Encoder support: 17/23-bit absolute encoder
  • Interfaces: RS232, RS485
  • Braking: no built-in braking resistor; external braking resistor supported
  • Protection: overvoltage, undervoltage, overspeed, overload
ModelJAND4002-20B
Rated power(W)400
Rated Current(A)2.8
Max current(A)9.6
Input powerSingle PhaseAC180-240V, 50/60HZ
CommunicationRS232:Connect to PC for Debugging + RS485:MODBUS protocol supported; motion control not supported
