57mm Integrated Servo Motor 100W (iHSV57-30-10-36)

Compact 57mm Integrated Servo Motor

The iHSV57-30-10-36 is a 57mm Integrated Servo Motor that packs 100 W of rated output into a 57 mm frame only 76 mm long, drawing 3.5 A at 3000 RPM. It is a compact integrated servo motor that mounts and wires like a single component, which suits small machines and cells where a full-size drive cabinet is disproportionate to the task.

Integrated closed loop Control

Position, speed, and current loops are closed digitally on the unit, with incremental encoder feedback used for commutation and speed control. The drive being integral to the motor removes the separate cable run between amplifier and windings, which shortens installation time and reduces wiring errors.

Thermal and Mechanical Notes

The 3.5 A continuous rating is the reference for torque at rated duty. Heat from both motor and drive is carried by the 57 mm frame, so the axis should be mounted with adequate airflow for continuous running. Low vibration helps maintain smooth motion at speed.

Key Specifications

• Frame size: 57 mm
• Body length: 76 mm
• Rated power: 100 W
• Rated current: 3.5 A
• Rated speed: 3000 RPM
• Encoder: incremental
• Integration: drive and motor in one unit

Integrated Axis Benefits

The single-unit design removes the separate amplifier from the panel and cuts the cable run between drive and motor, which lowers the risk of noise pickup and simplifies maintenance. For machines that are built in batches, the compact package also reduces installation time per axis and keeps the wiring schematic simple.

Applications

Robotics, industrial automation, packaging machinery, and CNC machine tools are typical applications for this compact integrated servo motor. The short 76 mm body is ideal for small rotary tables, pick-and-place modules, and laboratory-style automation where footprint is limited.

Selection Considerations

For this 57mm Integrated Servo Motor, confirm the supply voltage and current capability match the drive, and check that the 76 mm body length fits the mounting area. Because the frame is small, plan airflow for continuous operation. Our engineers can help verify the load torque and provide the correct wiring layout.
