400W 220V Servo Motor with 17-Bit Encoder

A Compact 400 W Servo for Space-Limited Axes

The 60JASM504230K-17BCZ-P is a 400W 220V Servo Motor rated at 1.27 N·m of continuous torque at 3000 r/min on a 60 mm frame. It includes an integrated holding brake and a 17-bit magnetic encoder. The compact physical envelope keeps the moving mass down, which is an advantage in equipment where space per axis is limited.

Compact Footprint and Dynamics

The 60 mm frame makes this one of the lighter servo motors in the high-voltage range, which pays off in reduced inertia on the coupled load and faster settling during rapid repositioning. Its 1.27 N·m of continuous torque at 3000 r/min covers moderate load applications that would be overkill for a larger frame. Because it still runs on 220 VAC, the motor keeps the wiring simplicity of the high-voltage series while occupying little panel and machine space.

Feedback and Brake

A 17-bit magnetic encoder closes the position loop with high resolution and tolerates workshop contamination better than optics. The holding brake keeps the shaft stationary whenever the servo enable is removed, which matters on vertical axes and on AGV/AMR drives that must hold position while stopped or on a gradient.

Key Specifications

• Rated voltage: 220 VAC
• Rated power: 400 W
• Frame size: 60 mm
• Rated torque: 1.27 N·m
• Rated speed: 3000 r/min
• Encoder: 17-bit magnetic
• Brake: integrated holding type
• Characteristics: high rotational speed, high performance, low noise

Applications

With its small frame and moderate torque, the motor suits packaging, robotics and factory automation equipment built around compact axes. It is also a good fit for textile, printing and food processing machinery, material handling and AGV/AMR traction, while remaining applicable to applications that need a dependable, space-saving closed loop drive.

Selection Considerations

Because the frame is small, confirm that continuous 400 W operation has adequate airflow and that the brake release voltage matches the machine controls. Lyenwsin supplies the 400W 220V servo motor with matched drives and application guidance.
